The ReachIR is new premium handheld observational thermal monocular series. All models come equipped with twelve micron infrared detector and a 1024×768 OLED display, for improved color rendering.
This Product is subject to ITAR/EAR Export Controls. Please visit our ITAR/EAR page (click here) or Contact Us for more Information.
The ReachIR thermal sensors also come equipped with the most sensitive temperature ratings in its class, coming in at sub-20 millikelvin across the entire product family. Other important options include a 1,000-meter integrated laser rangefinder (LRF), robust body and a removable, rechargeable 18650 battery. These units also boast an impressive waterproof rating, which ensures users have peace of mind while utilizing these under the vast majority of weather conditions.
New optimized image processing algorithms give thermal monocular highly optimized images and remarkable details. The ReachIRs built-in 64 GB memory also sits at the top of its class on the market, with advanced software supporting both video/audio recording and image capture. The primary uses for these thermal monoculars include, but are not limited to: hunting, law enforcement, search-and-rescue, personal security, conservation, anti-poaching, camping, hiking and different marine applications.
SPECIFICATIONS:
25-384:
- External Power: 5 VDC/2 A, USB Type-C interface. Supports external power supply.
- Dimensions: 181 × 53 × 85 mm (7.11 × 2.07 × 3.36 in)
- Weight (w/o batteries): 386 g (0.85 Ib)
- Palettes: Black Hot, White Hot, Red Hot, Fusion
- Working Temperature: -30°C to 55°C (-22°F to 131°F)
- Distance Measurement: Laser Rangefinder: up to 1,000 m, ±1 m accuracy
- Scene Mode: Jungle, Recognition
- Picture In Picture Mode (PIP): Yes
- Hotspot: Yes
- Video Recording: Yes
- Audio Recording: Yes
- Magnification: 2.5x – 20x
- Response Waveband: 8 μm to 14 μm
- FFC (Flat Field Correction): Auto, Manual, External Correction
- Highest Temperature Spot Tracking: Yes
- Standby Mode: Yes
- Refresh rate: 50 Hz
- Resolution: 384 × 288
- Detection Range (6' object): 1,200 m/yd
- Snapshot: Yes
- Lens system: 25 mm; F1.0
- NETD: Less than 20 mK (25°C, F#=1.0)
- Field of view (H × X): 10.5° × 7.9°
- Digital zoom: 1x, 2x, 4x, 8x
- Diopter adjustment range: -5 to +3 dpt
- Monitor: 1024x768, 0.39 inch, OLED, 50 FPS
- Storage: 64 GB EMMC
- Battery Type: One 18650 rechargeable battery (removable)
- Battery Operating Time: Up to 4.5 hours continuous running (@25°C, WiFi and LRF off)
- Battery Capacity Display: Yes
-
Protection Level: IP67 (Waterproof)
35-640:
- Magnification: 2.0x – 16x
- External Power: 5 VDC/2 A, USB Type-C interface. Supports external power supply.
- Dimensions: 185 × 53 × 88 mm (7.28 × 2.09 × 3.46 in)
- Weight (w/o batteries): 400 g (0.88 Ib)
- Palettes: Black Hot, White Hot, Red Hot, Fusion
- Working Temperature: -30°C to 55°C (-22°F to 131°F)
- Distance Measurement: Laser Rangefinder: up to 1,000 m, ±1 m accuracy
- Scene Mode: Jungle, Recognition
- Picture In Picture Mode (PIP): Yes
- Hotspot: Yes
- Video Recording: Yes
- Audio Recording: Yes
- Response Waveband: 8 μm to 14 μm
- FFC (Flat Field Correction): Auto, Manual, External Correction
- Highest Temperature Spot Tracking: Yes
- Standby Mode: Yes
- Refresh rate: 50 Hz
- Resolution: 640 × 512
- Detection Range (6' object): 1,800 m/yd
- Snapshot: Yes
- Lens system: 35 mm; F1.0
- NETD: Less than 20 mK (25°C, F#=1.0)
- Field of view (H × X): 12.5° × 10.0°
- Digital zoom: 1x, 2x, 4x, 8x
- Diopter adjustment range: -5 to +3 dpt
- Monitor: 1024x768, 0.39 inch, OLED, 50 FPS
- Storage: 64 GB EMMC
- Battery Type: One 18650 rechargeable battery (removable)
- Battery Operating Time: Up to 4.5 hours continuous running (@25°C, WiFi and LRF off)
- Battery Capacity Display: Yes
-
Protection Level: IP67 (Waterproof)
50-640:
- Magnification: 3.0x – 24x
- External Power: 5 VDC/2 A, USB Type-C interface. Supports external power supply.
- Dimensions: 197 × 60 × 95 mm (7.76” × 2.36” × 3.74”)
- Weight (w/o batteries): 450 g (1.0 Ib)
- Palettes: Black Hot, White Hot, Red Hot, Fusion
- Working Temperature: -30°C to 55°C (-22°F to 131°F)
- Distance Measurement: Laser Rangefinder: up to 1,000 m, ±1 m accuracy
- Scene Mode: Jungle, Recognition
- Picture In Picture Mode (PIP): Yes
- Hotspot: Yes
- Video Recording: Yes
- Audio Recording: Yes
- Response Waveband: 8 μm to 14 μm
- FFC (Flat Field Correction): Auto, Manual, External Correction
- Highest Temperature Spot Tracking: Yes
- Standby Mode: Yes
- Refresh rate: 50 Hz
- Resolution: 640 × 512
- Detection Range (6' object): 2,600 m/yd
- Snapshot: Yes
- Lens system: 50 mm; F1.0
- NETD: Less than 20 mK (25°C, F#=1.0)
- Field of view (H × X): 8.7° × 7.0°
- Digital zoom: 1x, 2x, 4x, 8x
- Diopter adjustment range: -5 to +3 dpt
- Monitor: 1024x768, 0.39 inch, OLED, 50 FPS
- Storage: 64 GB EMMC
- Battery Type: One 18650 rechargeable battery (removable)
- Battery Operating Time: Up to 4 hours continuous running (@25°C, WiFi and LRF off)
- Battery Capacity Display: Yes
-
Protection Level: IP67 (Waterproof)
